Imanes permanentes de neodimio
Foro svasato
COUNTERSUNK HOLE BLOCKS (Lateral Magnetization)
COUNTERSUNK HOLE Magnets must be fastened with a screw. The highest strength of this magnet is put on the thinner sides. It can be fixed directly on the furniture with a threaded screw, closing the doors perfectly.
| CODE | A | B | H | F | STRENGTH KG |
|---|---|---|---|---|---|
| NQ02.35NI00.1010 | 10 | 10 | 3 | 3,2 | 0,8 |
| NQ02.35NI00.15155F4 | 15 | 15 | 5 | 4,3 | 2,4 |
| NQ02.35NI00.2025 | 20 | 20 | 5 | 5 | 3,5 |
| NQ02.35NI00.40103 | 40 | 10 | 3 | 3,3 | 4,7 |
Max temperature 80 °C / Also available SH Type 150 °C. Physical Magnet data Sheet
The strength of attraction is purely indicative and it could be different depending on the type of application and assembly.
All measurements are in millimeters. Other sizes and shapes on request. |
